DALI Dimmer (Digital Addressable Lighting Interface)

DALI Dimmer (Digital Addressable Lighting Interface)

Using a compatible dimmer or DALI Driver with a DALI system allows for full dimming of LED Lighting products.

DALI controllers are used primarily to simplify and enhance lighting control. We keep stock of a range of DALI lighting control products including DT6 and DT8 dimmers to suit every install.

DALI dimming (digital addressable lighting interface) is recognised as an industry wide open standard protocol.

Filters
View as List Grid

Items 1-16 of 19

per page
Page
Set Descending Direction
  1. Sunricher AC Phase Cut & Push DALI Dimmer
    Product Code: SR2303SACHP

    This high quality Sunricher AC phase cut dimmer has both a DALI and a push switch control interface.  Suitable for both commercial and domestic applications it will switch and dim both mains powered LED and incandescent lamps (resistive and capacitive loads).  The unit works with 100v to 240v AC products up to 400w and is compatible with all DALI products

    ColourIP RatingInput VoltageOutput VoltageCRI Rating (greater than)
    White IP20 Non-Waterproof 240v AC 240v AC CRI >80
  2. Suricher DALI Scene Controller for Motion Sensors with Fixed Scenes
    Product Code: SR2412SCENESB

    The DALI scene controller is triggered by motion sensors and then recalls up to three preset DALI scenes which can be set on the device.  It can control one group of DALI devices on DALI line and the delay time can be set on the controller.

    ColourIP RatingInput Voltage
    White IP20 Non-Waterproof DALI Bus Powered
  3. Sunricher RF to DALI Receiver for Single Colour Group & Scene Control
    Product Code: SR2411RFDIM

    As part of our Sunricher range of LED control products, this high quality RF to DALI single channel Group and Scene Controller is powered from the DALI bus so there is no need for a separate driver.  The unit is compatible with all DALI lighting control system and compatible with many Sunricher RF single channel remote controllers.

    ColourIP RatingInput Voltage
    White IP20 Non-Waterproof DALI Bus Powered
  4. Sunricher RF to DALI DT8 Receiver for CCT Group & Scene Control
    Product Code: SR2411RFCCT

    This RF to DALI DT8 Group & Scene controller for tunable white LED Products receives an RF signal and outputs it to a DALI signal to the DALI line.  It is DALI bus powered and complies to DALI DT8 standard protocols IEC 62386-102, IEC 62386-207, IEC 62386-209.  The unit is compatible with all DALI lighting control system and with many Sunricher RF duel channel CCT remote controllers.

    ColourIP RatingInput Voltage
    Grey IP20 Non-Waterproof DALI Bus Powered
  5. Sunricher RF to DALI DT8 Receiver for RGBW Group & Scene Control
    Product Code: SR2411RFRGB

    From our Sunricher range of DALI products this feature rich RF to DALI Group & Scene Controller receives an RF signal and outputs a DALI signal to the DALI line.  It is compatible with DALI DT8 protocols for RGBW Colour changing from one DALI address and it can be used with all compatible DALI masters that support DT8 commands.

    ColourIP RatingInput Voltage
    Grey IP20 Non-Waterproof DALI Bus Powered
  6. Sunricher DALI Data Repeater with Built-in DALI Bus Power Supply
    Product Code: SR2400AMP

    From the Sunricher range of DALI products, this DALI repeater with integrated DALI bus power supply enhances the maximum DALI line length from 300 m up to 600m and the bidirectional transmission of the DALI signals.

    The maximum amount of products within a DALI system still remains as 64 DALI devices, the devices can be divided on the subordinate circuits as required.

    ColourIP RatingInput VoltageCRI Rating (greater than)
    White IP20 Non-Waterproof 100v - 240v AC CRI >80
  7. Sunricher DALI to 0-10V Converter
    Product Code: SR230301VPWM

    This DALI to 0-10v Signal converter will convert your DALI signal into a 0-10v signal that will control your existing 0-10v dimmable drivers.  This is especially useful when integrating your existing 0-10v products into a DALI control system.  It is ideal both commercial and domestic applications where a DALI system is used.

    ColourIP RatingInput VoltageOutput VoltageCRI Rating (greater than)
    White IP20 Non-Waterproof 100v - 240v AC 100v - 240v AC CRI >80
  8. Sunricher 4 in 1 LED DALI Dimmer With, Push, Phase Cut & 0-10V Inputs
    Product Code: SR2303P4IN1

    This Multi-function 4 in 1 PWM LED Dimmer works with DALI, Push, 0/1-10V and Phase Cut dimming interfaces.  These multi-selectable inputs make this a very desirable product with four input protocols catered for.

    ColourIP RatingWattageInput VoltageOutput VoltageCRI Rating (greater than)
    White IP20 Non-Waterproof 1 x 240w - 720w 12v / 24v / 36v DC 12v / 24v / 36v DC CRI >80
  9. Sunricher DALI Single Channel Dimmer
    Product Code: SR2303S

    This single channel DALI dimmer from our Sunricher range of DALI products has a 12v, 24v or 36vDC 8A output. It complies to DALI standards IEC 62386-102, IEC 62386-207 and matches all DALI systems in the market. One DALI address can be assigned by the DALI master.

    ColourIP RatingWattageInput VoltageOutput VoltageCRI Rating (greater than)
    White IP20 Non-Waterproof 1 X 96w - 288w 12v / 24v / 36v DC 12v / 24v / 36v DC CRI >80
  10. Sunricher DALI 4 x Channel DIN Mountable DALI Dimmer
    Product Code: SR2304DIN

    As part of our Sunricher range of LED control products, this high quality four channel universal DALI Dimmer is compatible with the DALI lighting control system.  Featuring manual or automatic DALI address settings, this product will integrate seamlessly with your existing DALI control system and is DIN rail mountable for installation purposes.

    ColourIP RatingWattageInput VoltageOutput Voltage
    White IP20 Non-Waterproof 4 x 60w - 180w 12v / 24v / 36v DC 12v / 24v / 36v DC
  11. Sunricher DALI 4 x 5A / Channel Dimmer with Push Dim
    Product Code: SR2304B

    As part of our Sunricher range of LED control products, this high quality four x 5A / channel universal DALI Dimmer is compatible with the DALI lighting control system.  Featuring manual or automatic DALI address settings, this product will integrate seamlessly with your existing DALI control system.
    Note: All four channel outputs work in synchronization.

    ColourIP RatingWattageInput VoltageOutput VoltageCRI Rating (greater than)
    White IP20 Non-Waterproof 4 x 60w - 180w 12v / 24v / 36v DC 12v / 24v / 36v DC CRI >80
  12. Sunricher DALI 4 x 8A / Channel Dimmer with Push Dim
    Product Code: SR2304BEA

    From our Sunricher range of DALI LED control products, this high quality 4 x 8A / channel universal DALI Dimmer is fully compatible with all DALI lighting control systems.  Featuring manual or automatic DALI address settings, this product will integrate seamlessly with your existing DALI control products.
    Note: All four channel outputs work in synchronization.

    ColourIP RatingWattageInput VoltageOutput VoltageCRI Rating (greater than)
    White IP20 Non-Waterproof 5 x 96w - 192w 12v / 24v / 36v DC 12v / 24v / 36v DC CRI >80
  13. Sunricher DALI DT8 RGBW Four Channel Dimmer
    Product Code: SR2309FARGBW

    This high quality four channel DALI Dimmer supports DALI DT8 protocols for RGBW dimming and colour control.  The unit can be configured using the DALI master USB interface and it is compatible with all DALI DT8 products and constant voltage RGBW LED products.

    ColourIP RatingWattageInput VoltageOutput Voltage
    White IP20 Non-Waterproof 4 x 60w - 180w 12v / 24v / 36v DC 12v / 24v / 36v DC
  14. Sunricher DALI DT8 Dimmer with Colour Type XY Coordinates
    Product Code: SR2309FAXY

    This high quality four channel DALI Dimmer supports DALI DT8 protocols for RGBW dimming and colour control.  The colour type, RGBW or XY coordinates can also be preset.   Works with all DALI DT8 products and constant voltage RGBW LED products.

    ColourIP RatingWattageInput VoltageOutput Voltage
    White IP20 Non-Waterproof 4 x 60w - 180w 12v / 24v / 36v DC 12v / 24v / 36v DC
  15. Sunricher DALI DT6 RGBW Four Channel Dimmer with Built-in DALI Master
    Product Code: SR2303FAOLED

    This multi function four channel DALI DT6 dimmer features a DALI Master function and has many features demanded by professional users. As the PWM frequency can be adjusted up to 30KHz this product is ideal for TV Studio applications where flicker free dimming is required.

    ColourIP RatingWattageInput VoltageOutput Voltage
    White IP20 Non-Waterproof 4 x 60w - 180w 12v / 24v / 36v DC 12v / 24v / 36v DC
  16. Sunricher DALI DT8 RGBW Four Channel Dimmer with Built-in DALI Master
    Product Code: SR2309FAOLED

    This multi function four channel DALI DT8 dimmer features a DALI Master function and has many features demanded by professional users. As the PWM frequency can be adjusted up to 30KHz this product is ideal for TV Studio applications where flicker free dimming is required.

    ColourIP RatingWattageInput VoltageOutput Voltage
    White IP20 Non-Waterproof 4 x 60w - 180w 12v / 24v / 36v DC 12v / 24v / 36v DC
Filters
View as List Grid

Items 1-16 of 19

per page
Page
Set Descending Direction

0-10V / PUSH / DALI Dimming; Benefits and which to choose?

Our LED lighting products are controllable using DALI and other similar lighting protocols. Below is a brief introduction to some of the most common protocols to best advise your lighting installation.

DALI (Digital Addressable Lighting Interface)

A DALI dimmer or Driver uses a low voltage signal to communicate, separate to the 240 AC feed. By assigning a DALI address, the DALI network can then identify the device and control the light output. DALI is a universal lighting protocol and is used to dim multiple lighting products through a single lighting interface.

0-10V dimming

Like DALI, 0-10V operates on a low voltage signal and communicates through a separate cable to the Mains feed. Unlike DALI, communication is only in one directional. 0-10V is a lighting standard and will work with any compatible product with a 0-10V output.

PUSH Dimming

Push dimming uses a simple retractive switch. The switch input to the driver is separate to the 240V AC feed similar to 0-10V and DALI control. When using PUSH dimming an additional live and neutral wire with a retractive switch connect to the driver.
