StudioFlex RGBNW LED Strip Light - 24V 150W IP67

Product Code: 101.149
  • RGB NW (4000-4500k) LED Strip Light
  • 14mm Wide PCB
  • 96 x Quad Colour LED's Per Metre
  • 30W Per Metre
  • Built with high quality materials
  • 5 Year warranty
  • 5 Metre Roll
  • Professional grade lighting solution
Currently in Stock
Next day delivery available*

In stock
Speak with an Expert
Speak with an Expert

Product Description

This StudioFlex RGBNW LED Strip is a dimmable product at 5M long reel with a colour rating of 4000-4500k & RGB. With a 120 degree beam angle & 10.4mm between LEDs at 96 p/m, running at 150w with an input voltage of 24v DC. This LED Strip has a size of 14x5.5x5000mm that can be cut at 63mm intervals.


LED Technologies range of StudioFlex LED strip tape offers a premium grade flexible lighting solution.

As our range of LED strip Lights grows we continually add new and innovative products to the range to meet our customer's high expectations. Our highest specification LED Strips that will meet the most demands of our customers, the Studioflex LED Strip lights are built using the highest grade materials to ensure brightness & durability.

Studioflex Strips have a high CRI rating which improves its ability to produce a pure white light and features high LEDs per metre, this helps reduce spotting and improves brightness. With a 5 year warranty. More StudioFlex information.

LED strip lighting is an alternative lighting solution to LED modules. All of our flexible LED tape lights have designated cutting points, allowing you to cut the strip to length. The LED strip lighting will fit into LED profiles, make sure to check their compatible sizes.


RGB Natural white (RGBNWworks by mixing different colours together to produce a final result. Where RGB LED strips feature a tricolour red, green and blue diode and RGBW features a quad colour diode. To produce a white RGB chip would have to mix red, green and blue together which can result in discolouration. RGBW LED Chips feature a dedicated white channel that can be powered to produce a pure white without mixing. This allows RGBW diodes to produce a pure white without discolouration caused by mixing. Quad colour LED chips are used frequently for professional use where colour changing & white are required.

An RGB Natural white LED strip is a 4 colour tape with an additional 4000 - 5500k Natural white channel. RGBNW is often used to create a relaxing feel in domestic and hospitality interior design.


Other RGB Whites:


LED controllers are able to adjust the brightness of each colour by altering the PWM frequency supplied to each channel. By adjusting the brightness of each colour to certain values the controller is then able to set the LED strip to specific colours.


IP67 - Waterproof:

The 6 stands for Totally protected against dust. The 7 stands for protected against temporary submersion. The test for this is between 15cm and 1m and of a duration of 30 minutes. An Example of where this Strip Light would be used would be in an outdoor environment where it is likely to get wet, so around perimeters of buildings.


Quick Specs

The guarantee period is the length of time a replacement or refund will be issued if the product becomes faulty and all operating and installation requirements have been met.
This is the required amount of volts needed to power the product.


  • TV Studios
  • Exhibitions
  • Theatres
  • Office Spaces

What's in the box?

  • 1 x 5 Metre Roll Of Strip
  • 10 x Bridging Clips for Fixing
  • 1 x Installation Guide
Product Code: 101.149
Product Packed N/A
Manufacturer LED Technologies
Product Type LED Strip Light
Colour RGB / Natural White
IP Rating IP67 Waterproof
LED per mtr
The amount of LED chips per 1 meter length.
96 p/Mtr
Metres 5 MTR
Colour Temperature
Colour Temperature refers to the coolness or warmth of the light produced by the LED's indicated in degrees Kelvin.
4000 - 4500K
Guarantee Period
The guarantee period is the length of time a replacement or refund will be issued if the product becomes faulty and all operating and installation requirements have been met.
5 Years
Wattage 150w
Current 1250mA/M
Input Voltage
This is the required amount of volts needed to power the product.
24v DC
Brightness Super High Brightness
PCB Weight 2oz
Size 14x5.5x5000mm Roll
Reel Length 5M
Beam Angle: 120 degree
LED Spacing 10.4mm
Lumens P/LED 15lm
Lumens P/Mtr 1500lm
CRI Rating (greater than) CRI >80
Dimmable: Yes
Cut Intervals: 63mm
LED QTY 96 LED Per Mtr
LED Type Led chip 5050
Continuous run 5 mtr
Average LED life Hrs 50,000
Peelable Back 300LSE 3M Adhesive Tape
Colour Temperature Variation IP20 No
Power Factor > Not Applicable
Wireless Range Up to 30 metres
Continuous Operation Not suitable for 24/7 continuous use
Base Type Tails
Datasheet - 101.149 Download
