NeoLED Green COB LED Strip 24V 50Mtr Roll (Free Cutting)
- Supplied on a 50m roll
- Pixel free single COB LED Strip
- One continuous band of light
- 24V constant voltage Input
- Can be cut freely between solder connections
- 5m maximum lengths
- 8mm wide circuit board
- Works with 8mm COB connectors
*We will endeavour to ship on time. Bulk/complex orders may ship the following working day.
Red 620-630nm
Blue 465-470nm
Orange 600-610nm
Yellow 1800 - 1900K
Pink 620-625nm
Cool White 6000-7000K
Natural White 3800 - 4200K
Daylight White 4800-5300K
Warm White 2800 - 3100K
Warm White 2600 - 2800K
Product Description
Supplied on a 50m roll for convenience, this excellent quality single COB LED "free cutting" LED Strip is available from our NeoLED range of professional products. This Seamless LED Strip is just 8mm wide enabling it to fit into narrow shallow LED profiles.
As the LED strip features pixel-free LEDs, the profile does not need to be deep to create a single line of bright green light. The light output of the strip is rated at 10W /m and should be powered by a suitable constant current 24V LED Driver. When connected to a suitable PWM controller the COB (chip on board) LED strip is fully dimmable.
Important: Although the LED Strip is supplied on a 50m roll, these LED Strip Lights can only be powered up to a length of 5 metres per driver, you cannot power the full 50m reel. Any additional length should be connected back to the power supply or up to 10m can be linked if powered from both ends.
This dotless LED Strip features an integral, high-quality 3M™ sticky backing to hold the LED Strip in place. This is the ideal lighting solution for projects where a bright Pixel-free light is required.
Warning: Do not apply power to the LED light strip while coiled on the 50m roll. Powering all 50m in one line (even off the roll) will damage the LED Strip. Please ensure you turn off the power to the LED strip when cutting or trimming the NeoLED strip.
For more information on the 50m NeoLed strip or any of our other LED products or professional control equipment, please contact our technical sales team by phone, email or via live chat and WhatsApp on our website.
Quick Specs
- Beam Angle:180 degree
- BrightnessSuper High Brightness
- ColourGreen
- Guarantee Period3 Years
- IP RatingIP20 Non-Waterproof
- Input Voltage24V DC
Applications
- Furniture
- TV Studios
- Exhibitions
- Theatres
- Office Spaces
- Living Areas
What's in the box
- 1 x 50 Metre Roll of NeoLED
- 1 x Installation Guide
Technical Specification
- Product Code: 102.131
- Product Packed Poly / Anti static Bag
- Manufacturer LED Technologies
- LED Strip Brands NEOLED Commercial
- Product Type LED Strip Light
- Colour Green
- IP Rating IP20 Non-Waterproof
- Metres 50 MTR
- Colour Temperature 520-525nm
- Guarantee Period 3 Years
- Wattage 10W/m
- Current 430mA/M
- Input Voltage 24V DC
- Brightness Super High Brightness
- Size 8mm x 1.8mm x 50,000mm Roll
- Reel Length 50M
- Beam Angle: 180 degree
- Dimmable: Yes
- LED Quantity 480 LED Per Mtr
- LED Type Chip on board (COB)
- Continuous run 5 mtr
- Average LED life Hrs 30,000
- Peelable Back 3M™ Adhesive Tape
- Voltage Type Constant Voltage
- Base Type N/A
- Strip Light Width 8mm
