360° Neon Flex Range | NEOLINEAR™

Product Code: 102.182
  • Bending with or without spine
  • White or Black colour available
  • End or side entry supply cable options
  • 360º of light
  • High light transmitting properties
  • Various fixing / hanging kits available
  • Single colours & colour changing available
  • Custom lengths made bespoke
  • Salt, acid, alkali corrosion, UV & fire resistant
24V DC

Bespoke Solution

This product is part of our Bespoke LED Solutions range. Customise this product with specifications that match your requirements. Contact our specialists for a quote today.

Fill out our to receive a call from our team.

Already have an Account? - Sign In No Account? - Create a Trade Account →

This Product is part of our Bespoke Range

This item is part of our Bespoke LED Solutions range. To proceed, please complete our Bespoke Enquiry Form or call us on 01260 540014 to discuss your requirements.

Product Description

From our Bespoke range of LED Lighting products, this 360º Neon product emits a uniform, pixel free light without any shadow and it is available either with a spine or without a spine. Products without a spine can be bent in any direction but will return back to their original shape after bending so although they are very flexible, to keep the shape required would require fixing clips to hold it shape. The product with a spine can only be bent in one direction however when bent, it will keep its shape without the need for clips. This option is ideal for making custom shapes in light and suspending them from a ceiling to create a dramatic effect. Various fixing kits are available to suspend the Neon using different types of fixings and we also have wall mounting clips to fix directly to a surface, this method of fixing is ideal for the non-spine version of the Neon. Options for customising the colour of the light emitted from the Neon include various colour temperatures of white, a colour temperature adjustable (CCT) option, solid colours including red, green blue, yellow and pink are available, or we can supply an RGB colour changing version if required. Note: CCT and colour temperature adjustable version are not available for the product with the spine. the neon can be produced in a standard white coloured silicone or with a black finish. For all enquiries about our range of 360º Neon products and to obtain a quote, please contact our Bespoke Project Department for additional help and advice by completing this contact form.

Quick Specs

  • CRI Rating (greater than)CRI >90
  • Beam Angle:360 degree
  • BrightnessSuper High Brightness
  • Guarantee Period3 Years
  • IP RatingIP65 Splashproof
  • Input Voltage24V DC

What's in the box

Depending on the bespoke options chosen, the package will include:
Bespoke length of 360º Neon.
Bespoke Fixing Kit
Data Sheet

Technical Specification

  • Product Code: 102.182
  • Product Packed Gift box
  • Manufacturer LED Technologies
  • IP Rating IP65 Splashproof
  • Guarantee Period 3 Years
  • Wattage 5W
  • Input Voltage 24V DC
  • Brightness Super High Brightness
  • Size 25mm Diameter
  • Beam Angle: 360 degree
  • CRI Rating (greater than) CRI >90
  • Dimmable: Yes
  • Average LED life Hrs 30,000
  • Voltage Type Constant Voltage
  • Base Type 15cm Tails at both ends
  • Strip Light Width 12mm
  • Strip Light Colour Single Colour
  • Unit Weight 350g appx

Product Datasheets

  • pdf Datasheet - 102.182 (Black) Download
  • pdf Datasheet - 102.182 (White) Download
